What an Open Winding in an Electric Motor Actually Means

An open winding in an electric motor means there is a break somewhere in the circuit where current is supposed to flow. Worth adding: instead of completing a continuous loop through the copper windings, the circuit is interrupted — like a wire that's been cut. No current can pass through that broken path, and the motor either won't start at all, runs poorly, or trips a protective device almost immediately.

This is one of the most common winding faults you'll come across in both single-phase and three-phase motors. It's also one of the more straightforward faults to wrap your head around, once you get past the jargon. The winding itself is the coil of wire wound around the stator (or rotor, in some designs) that creates the magnetic field needed to make the motor turn. When that winding is "open," the electrical path it provides is severed.

It can happen in the main run winding, the start winding in a single-phase motor, the field windings of a three-phase motor, or even in the connections between coils. Anywhere current is supposed to flow, a break kills the operation.

Why an Open Winding Matters

Here's the thing — a motor with an open winding isn't just "a little broken." It's fundamentally unable to do its job. The magnetic field that turns the rotor depends on current flowing through those windings. Consider this: cut the current path, and you cut the magnetic field. No magnetic field, no rotation.

In practical terms, this is the kind of failure that can stop a piece of equipment cold. Worth adding: a HVAC blower motor in a commercial building. A pump motor in an industrial process. A compressor motor in a refrigeration system. When the winding opens, production stops, cooling stops, or whatever the motor was driving simply doesn't work.

And it doesn't always fail catastrophically in a loud, obvious way. Sometimes the motor hums quietly but doesn't turn. Sometimes it draws a very high current on startup and trips a breaker instantly. Other times — particularly in three-phase motors running on two phases due to a single open winding — the motor might try to start in the wrong direction or run with severe vibration before eventually burning out completely.

The cost of ignoring it can be steep. Continued attempts to run a motor with an open winding can damage other components, including the motor's own insulation, the contactor, or the supply wiring. And if the open winding was caused by an underlying issue (overheating, voltage spike, mechanical stress), that root cause still needs addressing.

How to Find an Open Winding

Diagnosing an open winding isn't magic. It takes a multimeter, a little patience, and a logical approach.

Visual Inspection First

Before grabbing any tools, look at the motor. Which means burn marks, melted insulation, discolored wire, or a strong burnt smell are all telltale signs. Sometimes the break is physically obvious — a wire that's snapped, a connection that's come loose at a terminal post, or a spot where the winding has clearly overheated.

In single-phase motors, the centrifugal switch and its associated wiring are a common culprit. Over time, the switch contacts wear out, wires flex and break, and the start winding circuit can go open. The switch is supposed to disconnect the start winding once the motor reaches running speed. A lot of "bad motors" that get scrapped are actually motors with a bad switch, not bad windings.

Continuity Testing

The most direct test for an open winding is a simple continuity check with a multimeter. Set the meter to resistance or continuity mode and measure across the winding terminals.

A healthy winding will show a low resistance value — typically somewhere in the low single digits of ohms for most fractional-horsepower motors, and sometimes a fraction of an ohm for larger motors. An open winding will show infinite resistance (or "OL" on a digital meter, meaning "over limit" or "open loop"). That infinite reading is your confirmation: the circuit is broken.

For three-phase motors, you test between each pair of leads (U-V, V-W, W-U). Day to day, all three pairs should show roughly the same resistance. If one pair reads open while the other two read normally, you've found your fault.

Insulation Resistance Testing

A megohmmeter (megger) test takes things further. That's why it applies a high voltage between the winding and the motor frame to check the integrity of the insulation. While this test is more about insulation breakdown than open windings per se, it helps rule out a winding that's failed to ground — which can sometimes look like an open circuit from certain test points.

Megohmmeter vs. Multimeter — What's the Difference?

Real talk: a multimeter tells you if the circuit is continuous. Think about it: a motor can have perfectly fine continuity but terrible insulation (and vice versa). A megohmmeter tells you if the insulation is still doing its job. Even so, they're complementary, not interchangeable. For a complete picture, you want both.

What Causes an Open Winding

Open windings don't just happen out of nowhere. There's always a reason, and finding the reason matters as much as finding the fault.

Thermal Stress

This is the big one. Motors generate heat when they run, and that heat gradually degrades the enamel coating on the winding wire. Also, once the insulation fails, adjacent turns of wire can short together, which creates localized heating, which causes more insulation failure, and so on. Over time — or much faster if the motor is overloaded, has a failing bearing, has poor ventilation, or runs in a hot environment — that insulation breaks down. Eventually, a wire can melt through entirely, creating an open circuit.

Mechanical Stress

Vibration, impact, or thermal cycling (repeated heating and cooling) can crack solder joints, break lead wires, or fatigue the copper itself. Motors that start and stop frequently are more vulnerable to this than motors that run continuously.

Voltage Spikes

Surge events — from the supply side or from switching inductive loads — can punch through winding insulation. After enough spikes, the insulation fails and you get a winding fault. Variable frequency drives (VFDs) are a known contributor here, especially if the motor wasn't designed for inverter duty or the cable length between drive and motor is too long.

Contamination and Moisture

Water, oil, chemicals, and conductive dust can all attack winding insulation. A motor in a wet environment or one that has been flooded is at high risk of winding failure, open or otherwise.

Poor Manufacturing or Repair Work

Sometimes the cause is human. A bad crimp, a cold solder joint, a pinched wire during assembly, or a sloppy rewind job can all lead to an open winding showing up much sooner than it should.

Common Mistakes When Dealing with an Open Winding

A few things trip people up more than they should.

Assuming the Motor Is Scrap

Not every open winding means the motor is junk. If the fault is in an accessible connection, a broken lead wire, or a failed centrifugal switch, a competent repair shop can often fix it for a fraction of the cost of a new motor. Even a burned-out main winding can sometimes be rewound. The decision between repair and replacement depends on the motor's size, age, and the cost of a replacement.

Replacing the Motor Without Finding the Cause

Here's one that costs people real money. Because of that, they swap in a new motor, hit start, and the new motor fails in a few weeks because the real problem was upstream — a bad capacitor, a weak supply phase, an overloaded driven load, or a mounting issue causing bearing failure. Always investigate why the winding opened before installing a replacement.

Confusing an Open Winding With Other Faults

A motor that hums and won't start could have an open winding, but it could also have a failed start capacitor, a bad centrifugal switch, a seized bearing, or a mechanical jam. Plus, don't jump to conclusions. Test before tearing things apart.

Skipping the Start Circuit on Single-Phase Motors

When a single-phase motor won't start, people often check the main winding and stop there. Now, the start winding, the start capacitor (if equipped), and the centrifugal switch are all common failure points. An open start winding will prevent the motor from starting just as effectively as an open run winding.

What Actually Works — Practical Tips

A few things have saved me time and headaches over the years when dealing with open windings.

Continue exploring with our guides on what are you up to or too and what is 38.2 c in fahrenheit.

Always disconnect and lock out the motor before testing. Capacitors in motor circuits can hold a dangerous charge even after the power is off. Discharge them safely before touching anything.

Keep a baseline. If you're responsible for a fleet of motors, record the resistance of each winding when the motor is new or freshly serviced. When a motor later acts up, you have a known-good value to compare against. A winding that's drifted significantly in
